Tablet Press Machine

We are leading manufacturer, supplier & exporter of Tablet Press Machine in Ankleshwar, Gujarat, India.

The efficient way for double rotary tableting. This Double Rotary Tabelling / Tablet Press Machine is built as per the GMP directives with total robust construction. Double Rotary Tabelling / Tablet Press Machine is very useful for small to medium batch size production. Easy operation and maintenance of this machine make it very much popular.

Salient Features of Tablet Press Machine:

Square GMP Model
Machine is Having C.I. Body and C.I. Middle plate
Machine is Having CROMPTON GREAVES MAKE MOTOR.
Paint free tablet manufacturing zone.
Turret of Special Grade S.G. Iron casting, It is Three Piece Turret with turret teeth ring fitted separately.
SS 316 Middle plate in Turret is also available optionally.
Upper punch penetration
Electronic Digital Tablet cum RPM Counter
Inter lock Switches to all Guards.
Double Sided lifting cams
Lower Guard of polished Stainless Steel & Upper Guards of Acrylic Material
Aluminum Turret Guards
Effective Dust Extraction Nozzles
Imported needle roller bearing provided at the bottom of turret.
Variable Speed pulley, one shot Lubrication System, Anti Vibrating mounts
Reverse direction motion protection is provided to avoid accident.
Available with AC variable Drive for Main motor

Technical Details of Tablet Press Machine:

Number of Station : 27
Type Of Tooling : ‘D’
Output tablets / hour : (MAX.) 1, 29,000 (40 RPM)
Max. Operating Pressure : 10 Tons
Max. Tablet Diameter : 25 mm
Depth of Fill : 20 mm
Upper Punch Penetration : 1.5 – 8 mm
Main Electrical Motor : 7.5 HP X 1440 RPM X 3 PH X 415 V X 50 Hz
Overall Dimension (cm) : 1790 mm X 1000 mm X 1040 mm
Net Weight : 1400 Kg. Gross Weight : 1800 Kg.
Case Dimension (cm) : 60” X 52” X 83” H
